Australian Standard

Grade V400 Chain (Australian Standard)

Grade V400 Chain (Australian Standard) is heat treated alloy steel chain. This chain is primarily used as a sling component for overhead lifting, but can also be used in rigging and tie-down applications where a lighter weight, higher strength chain is desirable. The chain link is marked every 3 feet with TKC and V400 in order to identify manufacturer and grade. The chain is heat treated with Quenching and Tempering method. Grade V400 chain is tested proof load, bending deflection with Open Crosshead Computer Servo Hydraulic Universal Testing Machine and tested hardness with Digital Rockwell Type Hardness Tester. Lastly, chain is calibrated to the dimensional requirements for properly size. Grade V400 chain is manufactured to meet Australian Standard AS 2321 specification.

  • Available Sizes :

  • 5 มม. – 16 มม.
  • Available Surfaces :

  • Self Colored
  • Bright Polished
  • Zinc Coated
  • Powder Coated
  • Black Oxide Coated
  • Hot-Dip Galvanized
CAUTION: Never exceed the working load limit of chain.
 USE FOR OVERHEAD LIFTING
TECHNICAL DATA
File list Download
Australian Standards Grade V400 Download
